Hydraulic Impact Wrench Stanley IW24

Stanley IW12 Hidrolik Darbeli Somun Sıkma Sökme

The Stanley IW24 Hydraulic Impact Wrench is a heavy duty wrench ideal for nut and bolt driving, screw anchor and other heavy impact applications.

Designed to run from a wide range of hydraulic circuits, the IW24 has adjustable impact intensity making it ideal for a wide range of heavy duty driving.

The large “D” handle and feathering trigger are convenient and gives the operator complete control of the wrench.

The rugged swing-hammer impact mechanism provides easy servicing for reduced maintenance costs and greatly reduces the transmission of torque to the operator reducing fatigue through repetitive tool operation.

Just set the direction of rotation to either tighten or loosen a fastener, squeeze the trigger for up to 3500 ft lbs (4760 Nm) of torque


Features:

(+) Adjustable impact intensity from 1088 to 4760 Nm

(+) Swing-hammer mechanism

(+) Feathering trigger and “D” handle

(+) Reversing valve for instant change

(+) 1-1/2 inch square drive

(+) Reverse

unite    hidro    ismakinasi    kamyon 1    traktor

uygulama-hidrolik-ekipman

logo-stanley
IW24

TECHNICAL
SPECIFICATIONS

Chuck Type
1-1/2" (38 mm) Sq.
Torque
1088-4760 Nm
Hydraulic Flow
26-45 lpm
Hydraulic Pressure
124-140 bar
Weight
20 kg
Length
41 cm
Width
13 cm
Couplers
HTMA Flush Face


Underwater Model
IW24 uw
